Semiconductor Laser Light Aerosol Photometer Detect Leaking Test

Semiconductor Laser Light Aerosol Photometer Detect Leaking Test
Semiconductor Laser Light Aerosol Photometer Detect Leaking Test

Large Image :  Semiconductor Laser Light Aerosol Photometer Detect Leaking Test

Product Details:
Place of Origin: China
Brand Name: SUJING
Model Number: Y09-310DL
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: negotiable
Packaging Details: Carton
Delivery Time: 5 work days
Payment Terms: T/T
Supply Ability: 100unit/week
Detailed Product Description
Name: Y09-310DL Detect Leaking Test Equipment Aerosol Photometer Size Channels: 0.3,0.5,1,3,5μm (Six Channels)
Size: ≥0.3μm Flow Rate: 28.3L/min ±5%
Zero Count: ≤10min Warranty Time: 1 Year
High Light:

Semiconductor Laser Light Digital Aerosol Photometer

,

Detect Leaking Aerosol Photometer

,

Six Channels Digital Aerosol Photometer

Y09-310DL Detect Leaking Test Equipment Aerosol Photometer



This instrument uses semiconductor laser light source, touch screen LCD display, reasonable structure, high detection accuracy, large flow, short sampling time, simple and clear function operation. No need for computer data collection, it can be directly stored in storage media such as U disk, or it can be controlled by computer, can store and print sampling results, built-in thermal micro printer, the test environment is very convenient



Feature of Y09-310DL

  • Flow rate 28.3L/min ,Minimum Size channel 0.3 μm
  • Partices couting and leaking detection
  • Replaceable battery

Main Parameter of Y09-310DL

Size Channels 0.3,0.5,1,3,5μm (Six Channels)
Size ≥0.3μm
Flow Rate 28.3L/min ±5%
Repeatability Relative Error ≤10%
Particle size distribution error ≤±30%
Indication error of particle size ≤±20%
Zero Count ≤10min
Insulation resistance ≥50MΩ
Maximum counting concentration

≤3.5*105P/28.3L

Scan Speed 3-5cm/s
Distance between probe and filter outlet surface 2-3cm
Power  DC16.8V
