APM-18 Digital Aerosol Filter Photometer ISO-14644 220VAC

APM-18 Digital Aerosol Filter Photometer ISO-14644 220VAC

Brand Name: SUJING
Model Number: APM-18
MOQ: 1
Price: Negotiable
Payment Terms: T/T
Supply Ability: 800/per month
Detail Information
Place of Origin:
China
Name:
APM-18 Digital Aerosol Photometer Filter Leak Detector
Reagent Settings:
PAO-4, DOP, Ondina, Mineral Oil, Paraffin
Output:
Wireless Printer, USB Interface
Standards Compliance:
NSF 49, IEST, ISO-14644
Light Source:
Solid State, Rated For Life Of Instrument
Warranty Time:
1 Year
Packaging Details:
Carton
Supply Ability:
800/per month
Highlight:

Digital Aerosol Filter Photometer

,

ISO-14644 Filter Photometer

,

220VAC Filter Photometer

Product Description

APM-18 Digital Aerosol Photometer Filter Leak Detector



The aerosol photometer is small in size, light in weight and easy to carry. It is the latest portable pointer photometer, also known as filter leak detector.
The instrument is controlled by a microcomputer processor, and the instrument parameters .The coefficients of aerosol DOP.PAO can also be set in the body. The main body directly displays the test data.



APM-18 photometer Specifications
Dynamic Range Up to 600 micrograms per liter
Reagent Settings PAO-4, DOP, Ondina, Mineral Oil, Paraffin
Auto Zero Automatically establishes zero reading at startup
Sensitivity 1% of readings ≥0.01% to 100%
Repeatability 0.5% of readings ≥0.01% to 100%
Flow Control Pulse Width Modulation (PWM) control ensures sampling rate of 1cfm (28.3lpm) +/- 10% in all applications.
Light Source Solid State, rated for life of instrument
Reporting Continuous, Summary, and Monitoring modes
Alarm User selectable audible, visual, and vibratory alarms notify the user when the user defined set point is exceeded.
Size 260 (W)X160(H)X360(D)
Weight 10Kg
Output Wireless printer, USB interface
Power 220VAC, 50/60HZ
Standards compliance NSF 49, IEST, ISO-14644



Application of digital aerosol photometer

  • leakage detection of clean room
  • VLF bench
  • biosafety cabinet
  • glove box
  • HEPA vacuum cleaner
  • HVAC system
  • HEPA filter
  • negative pressure filtering system
  • operating theatre
  • nuclear filter system
  • collection protect filter
