Laboratory Filter Testing Aerosol Generator Y09-AG310PS 2000cfm

Basic Information
Place of Origin: China
Brand Name: Sujing
Model Number: Y09-AG310PS
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Carton
Delivery Time: 5 work days
Payment Terms: T/T
Supply Ability: 800/per month
Detail Information
Name: Y09-AG310PS 50-2000cfm (1.4-56.6m³/Min) Aerosol Generator Flow Range: 50-2000cfm (1.4-56.6m³/min)
Generating Aerosol Type: Polydispersed Particles, PAO, DOP Generating Method: 1-6 Laskin
Warranty Time: 1 Year Weight: 8kg
High Light:

SS Aerosol Generator


Aerosol Generator 2000cfm


PAO Laboratory Aerosol Generator

Product Description

 Y09-AG310PS 50-2000cfm (1.4-56.6m³/Min) Aerosol Generator
This type of generator is typically capable of spraying aqueous solutions (e.g. salt), suspensions , or oil or alike substances. They serve a variety of applications from laboratory research field tests of detectors, and filter testing.
Characteristic of aerosol generator

  • Condensing oscillation generates, built-in compressor, no need of other air source.
  • PAO or DOP can be generated by 1-6 Laskin.
  • Professional team development and production, with patented technology, quality assurance.


Specifications of aerosol generator
Name Aerosol generator
Model Y09-AG310PS
Flow range 50-2000cfm (1.4-56.6m³/min)
Concentration 10ug/L 2000cfm;100ug/L 200cfm;
Aerosol type Polydisperse particles (cold), PAO-4, DOP
Mode 1-6 Laskin output
Compressed air Do not need (built-in air compressor)
Housing 316 stainless steel shell belt handle
Size 430x298x268mm
Weight 18Kg
Power 220V AC, 50/60HZ



Company Information

Suzhou Sujing Automation Instrument Equipment Co., Ltd. (herein after referred to as Sujing Instrument) is boasting the largest market share in the particle measurement field in China, with complete integration of scientific research, development and production.

Sujing Instrument is one subsidiary company of Sujing Group.(Sujing Group has 11 subsidiary companies)

Sujing brand has been granted the honor of "China Famous Brand" since 1983. Sujing Group has been keeping the first place among competitors in the same industry for 35 years in a row.
The mission of Sujing Instrument is to provide products and services accociated with particle measurement and monitoring, which are application driven.



Sujing instrument is an ISO 9001:2015 Registered Company
