Six-Channel Simultaneous Air Particle Counter Y09-6CH
Y09-6CH Six-Channel Simultaneous Air Particle Counter with Advanced Laser Diode Sensor Array
The Y09-6CH Six-Channel Simultaneous Air Particle Counter sets a new benchmark for multi-channel particle measurement by delivering true parallel detection across all six size channels in real time. Unlike sequential scanning instruments that measure one channel at a time, the Y09-6CH employs a sophisticated optical detection system with a precision laser diode sensor array that simultaneously captures and categorizes particles across the complete 0.3 to 10.0 micrometer spectrum in a single measurement cycle. This simultaneous architecture eliminates temporal bias, ensures perfect correlation between channel data, and delivers the most accurate representation of airborne particle size distribution achievable with current laser-based particle counting technology.
The instrument is purpose-built for rigorous cleanroom monitoring applications where data integrity and measurement reproducibility are paramount. Its advanced signal processing algorithms incorporate real-time coincidence loss correction, ensuring measurement accuracy even in high-concentration environments up to 2,000,000 particles per cubic foot. The Y09-6CH features robust industrial-grade construction with an IP54-rated enclosure that protects internal optics from environmental contaminants, making it suitable for both routine cleanroom surveys and extended continuous monitoring deployments. The large 7-inch color touchscreen display provides simultaneous visibility of all six channel readings with customizable data views including particle count tables, size distribution histograms, and real-time trend graphs.
Key Features| Parameter | Specification |
|---|---|
| Flow Rate | 100 L/min (3.53 CFM) |
| Particle Size Channels | 0.3, 0.5, 1.0, 3.0, 5.0, 10.0 μm (Simultaneous) |
| Detection Method | Laser Diode Light Scattering (90-degree Collection) |
| Counting Efficiency | 50% at 0.3μm; 100% at >0.5μm per ISO 21501-4 |
| Maximum Concentration | 2,000,000 particles/cf (Coincidence Loss ≤5%) |
| Zero Count | ≤1 count per 10 minutes (95% upper confidence limit) |
| Flow Control | Closed-loop electronic mass flow controller |
| Sample Time Settings | 1 second to 99 hours, 0.1 second resolution |
| Sample Modes | Single, Cyclic, Continuous, Grid, Statistical |
| Alarm System | Per-channel configurable thresholds with audible and visual alerts |
| Printer | Built-in 58mm thermal printer, 45mm/second print speed |
| Power | AC 100-240V 50/60Hz; Li-ion battery 6+ hours continuous |
| Operating Environment | 10°C-40°C, 20%-90% RH, 86-106 kPa |
| Dimensions (W x D x H) | 320 x 290 x 155 mm |
| Weight | 6.0 kg (including battery and printer) |
The Y09-6CH Six-Channel Simultaneous Air Particle Counter serves a broad spectrum of cleanroom monitoring and air quality verification applications. In pharmaceutical manufacturing, the instrument supports environmental monitoring programs for aseptic processing areas (Grade A/B), controlled production zones (Grade C/D), and quality control laboratories in compliance with EU GMP Annex 1 and USP 797/800 standards. The simultaneous measurement capability provides comprehensive particle size distribution data required for thorough pharmaceutical environmental risk assessments and regulatory inspection readiness.
In the semiconductor and microelectronics industry, the Y09-6CH delivers critical contamination monitoring for cleanroom zones ranging from ISO Class 1 through Class 8, supporting photolithography, wafer processing, packaging, and test areas. The instrument also serves aerospace component manufacturing, medical device cleanroom assembly, biotechnology research laboratories, optical component manufacturing, data center air quality monitoring, and industrial HEPA/ULPA filter certification operations. Contract testing organizations rely on the Y09-6CH for third-party cleanroom validation services benefiting from its comprehensive reporting capabilities and multi-standard compliance support.
Packaging & Quality AssuranceEach Sujing air particle counter is carefully packaged in a durable export-grade carton with high-density foam inserts ensuring maximum protection during international shipping. Standard packaging includes the main instrument unit, isokinetic sampling probe, power adapter with charging cable, zero-count filter, thermal printer paper roll, USB communication cable, PC software installation media, calibration certificate, comprehensive user manual, and protective carrying case. All shipments undergo thorough pre-dispatch inspection including functional testing across all six particle channels, zero-count verification, flow rate calibration check, and communication interface testing.
Sujing Instrument maintains an ISO 9001:2015 certified quality management system with complete traceability from raw material sourcing through final product delivery. Each instrument undergoes rigorous quality assurance testing including 24-hour burn-in, multi-point calibration verification, and full functional validation before release. We provide comprehensive after-sales support including a 12-month standard warranty, lifetime technical consultation, remote diagnostic assistance, and optional on-site calibration with maintenance services performed by factory-trained technicians. Our global service network covers over 60 countries worldwide.
For regulated industries requiring formal cleanroom compliance documentation, we provide complete qualification and validation support packages including Installation Qualification (IQ), Operational Qualification (OQ), and Performance Qualification (PQ) protocols upon request. Our application engineering team is available to assist with custom configurations and specialized monitoring solutions.
