Clean Space Aerosol Photometer With Pump Type Y09-AG310PS

Basic Information
Place of Origin: China
Brand Name: Sujing
Model Number: Y09-AG310PS
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: CartonY09-AG310PS Clean Space Aerosol Generator With Pump Type
Delivery Time: 5 work days
Payment Terms: T/T
Supply Ability: 800/per month
Detail Information
Name: Y09-AG310PS Clean Space Aerosol Generator With Pump Type Flow Range: 50-2000cfm (1.4-56.6m³/min)
Generating Aerosol Type: Polydispersed Particles, PAO, DOP Generating Method: 1-6 Laskin
Warranty Time: 1 Year Weight: 18kg
High Light:

Polydispersed Particle Aerosol Photometer


Pump Type Aerosol Diluter


Fast Heating DOP Aerosol Photometer

Product Description

Y09-AG310PS Clean Space Aerosol Generator With Pump Type


 Aerosol generator and aerosol photometer are used to detect the leakage efficiency of high efficiency filter. When the aerosol generator is combined with aerosol photometer, the defects of the filter, such as pinhole, leakage point, gasket leakage, internal leakage, or frame leakage, can be quickly detected, and timely correction and relevant measures can be taken to ensure the efficiency of the high efficiency filter and the cleanliness level of the ultra clean room


The aerosol generator is developed by our company and the production of portable cold aerosol generator, It can meet the requirements of the HEPA filter test for all small cleaning units to the large clean room air supply system.It produces a continuous, stable aerosol particle and is convenient to add the solution


Characteristic of aerosol generator

  • Condensing oscillation generates, built-in compressor, no need of other air source.
  • PAO or DOP can be generated by 1-6 Laskin.
  • Professional team development and production, with patented technology, quality assurance.

Clean Space Aerosol Photometer With Pump Type Y09-AG310PS 0

Specifications of aerosol generator
Name Aerosol generator
Model Y09-AG310PS
Flow range 50-2000cfm (1.4-56.6m³/min)
Concentration 10ug/L 2000cfm;100ug/L 200cfm;
Aerosol type Polydisperse particles (cold), PAO-4, DOP
Mode 1-6 Laskin output
Compressed air Do not need (built-in air compressor)
Housing 316 stainless steel shell belt handle
Size 430x298x268mm
Weight 18Kg
Power 220V AC, 50/60HZ
