Laboratory Liquid Electronic Particle Counter FDA 21 CFR Part 11
|
Laboratory Liquid Electronic Particle Counter FDA 21 CFR Part 11
| Brand Name: | SUJING |
| Model Number: | LE100 |
| MOQ: | 1 |
| Price: | Negotiable |
| Payment Terms: | T/T |
| Supply Ability: | 800/per month |
Detail Information
Place of Origin:
China
Name:
Liquid Particle Counter Compliant With FDA 21 CFR Part 11 In Lab
Particle Size Channel:
24
Display:
7inch LCD Color Touch Screen
Sample Stirring Method:
Magnetic Stirring (adjustable)
Data Output:
RS232 Port, USB, Built-in Printer
Warranty Time:
1 Year
Packaging Details:
Wooden Case
Delivery Time:
5 work days
Supply Ability:
800/per month
Highlight:
RS232 Electronic Particle Counter
,LE100 Electronic Particle Counter
,FDA Electronic Particle Counter
Product Description
Liquid Particle Counter Compliant With FDA 21 CFR Part 11 In Lab
This liquid particle counter complies with USP <788>, USP <789> and other standards.
| Technical parameters | liquid particle counter |
| Particle size range | 2-100 μm |
| Particle size channel | 24 |
| Maximum detection concentration | 10000 particles/ml |
| Accuracy | ±10% |
| Repeatability | RSD<2% (particles>1000 per ml, 5ml sample) |
| Resolution | <10% (U.S.P, ISO 21501) |
| Syringe specifications | 1ml, 5ml, 10ml*, 25ml |
| Sampling speed | 20 ml/min* |
| Sample volume accuracy | ±1% |
| Minimum sampling volume | 0.2ml** |
| Sensor material | 316 stainless steel, quartz glass, PTFE, NBR |
| Power supply | AC 100~240V, 50/60HZ |
| Mixing method | Magnetic stirrer (speed adjustable) |
| Data output | RS232 port; USB; built-in thermal printer |
| Display output | 7 inch LCD color touch screen |
| Size | 320(L)×309(W)×394(H) mm |
| Weight | 11.0 kg |
| Operating environment | Temperature 10-40 ℃; RH 0 ~ 95% non-condensing |
| Software system | LE-Assistant (optional) |
|
* Standard configuration ** Under 1ml syringe specifications the minimum sampling volume is 0.2ml, under the standard configuration, the minimum sampling volume is 0.4ml |
|
Features of liquid particle counter
-
Built-in USP testing standards -
Precision syringe sampling device, accurate sampling volume, stable speed -
Built-in calibration curve, in line with calibration requirements of ISO-21501 -
Intelligent automatic detection and automatic calibration function, instrument performance judgment and calibration -
Use of magnetic stirring, stirring speed adjustable -
USB interface direct export data, paperless electronic print report -
Powerful application software development support. Easy to connect to the laboratory information management system etc. -
The LE-Assistant software implements PC control and provides professional data processing -
Compliant with FDA 21 CFR part 11 "Electronic Records and Signatures" and user rating management
