| Place of Origin: | CHINA |
|---|---|
| Brand Name: | SUJING |
| Model Number: | DHP-II |
| Minimum Order Quantity: | 1 |
| Price: | Negotiable |
| Packaging Details: | Carton |
| Delivery Time: | 5 work days |
| Payment Terms: | T/T |
| Supply Ability: | 500unit/per month |
| Name: | DHP-II High Pressure Diffuser Compressed Air Particle Counter | Sample Pressure: | 30~150psi（0.2MPa~1MPa） |
|---|---|---|---|
| Sample Type: | Dry Gas, Inert Gas, Non-toxic And Harmless Gas | Flow Match: | 2.83L, 28.3L, 50L, 100L (with A Set Of Nozzle Joints) |
| Model Match: | Y09-3016, Y09-301, Y09-310, Y09-550, Y09-5100, FKC Series | Warranty Time: | 1 Year |
| High Light: | high pressure diffuser for particle counter,DHP-II high pressure diffuser for particle counter,2.83L high pressure diffuser for particle counter |
||
DHP-II High Pressure Diffuser Compressed Air Particle Counter
DHP-II High Pressure Diffuser Compressed Air Particle Counter is developed on the basis of former DHP-I type, based on ISO14644-1:2015, ISO8573-4:2019 and other related standards. During use, DHP-II directly connects high-pressure gas, and the high-pressure gas is converted into atmospheric gas inside, which is convenient for particle counter or microbial air sampler to sample and analyze the gas.
Features of Compressed Air Particle Counter
| Technical specifications of compressed air particle counter | |
| Model | DHP-II |
| Sample pressure | 30~150psi(0.2MPa~1MPa) |
| Sample type | Dry gas, inert gas, non-toxic and harmless gas |
| Flow match | 2.83L, 28.3L, 50L, 100L (with a set of nozzle joints) |
| Model match | Y09-3016, Y09-301, Y09-310, Y09-550, Y09-5100, FKC series |
| Power supply | None |
| Dimension | 20cmxφ6cm (not include bracket and filter size) |
| Material | SUS316L |
| Weight | 2.5KG |
The picture of compressed air particle counter
