|Name:||Air Pollution Quality Monitor Handheld Particulate Matter Detector||Flow Rate:||0.1cfm|
|Detection Range:||0.1-999.9μg /m3||Sensor:||Laser Snesor|
|Warranty Time:||1 Year||Application:||Cleanroom|
10W Air Pollution Quality Monitor,
PM10 Air Pollution Quality Monitor,
Handheld Particulate Matter Detector
Air Pollution Quality Monitor Handheld Particulate Matter Detector
The dirt particles in the air have the function to scatter the incident light. The density of scattered light is related to grain size. The air containing dirt particles is sucked in from sampling port of the sensors. When it passes through the photoactive area, the dirt particles are shined by the light to scatter optical pulses signal with certain proportion to particle size. The signal is received by photosensor and is converted to corresponding electric pulse signal and then is amplified. By counting the electric pulse in one detection cycle, the quantity of dirt particles in the detected air with unit volume is obtained. This is also the particle concentration.
The parameter of Y09-PM10 Air Quality Monitor
|Power Source||DC8.4 V built-in Lithium Battery|
|Size channels||PM1.0 PM2.5 PM10|
|Flow Rate||2.83L/min (Imported Pump)|
|Sample Time||0-999999s Selectable|
|Printer||External thermal printer(optional)|
|Detection Range||0.1-999.9μg /m3|
|Data Storage||1000 records|
|Light Source||Laser Diode (30000 hours mean time between failures)|
|Operating Time||5 hours|
|Accessories||Carry case ;zero count filter; AC adapter; pc cable; pc software|
Suzhou Sujing Automation Instrument Equipment Co., Ltd. (herein after referred to as Sujing Instrument) is boasting the largest market share in the particle measurement field in China, with complete integration of scientific research, development and production.
Sujing Instrument is one subsidiary company of Sujing Group.(Sujing Group has 11 subsidiary companies)
Sujing brand has been granted the honor of "China Famous Brand" since 1983. Sujing Group has been keeping the first place among competitors in the same industry for 35 years in a row.
The mission of Sujing Instrument is to provide products and services accociated with particle measurement and monitoring, which are application driven.
Sujing instrument is an ISO 9001:2015 Registered Company
