7inch Touch Screen Laser Particle Counter 28.3L/Min Flow Y09-310NW

Certification
China Suzhou Sujing Automation Equipment corporation limited certification
China Suzhou Sujing Automation Equipment corporation limited certification
I'm Online Chat Now

7inch Touch Screen Laser Particle Counter 28.3L/Min Flow Y09-310NW

7inch Touch Screen Laser Particle Counter 28.3L/Min Flow Y09-310NW
7inch Touch Screen Laser Particle Counter 28.3L/Min Flow Y09-310NW

Large Image :  7inch Touch Screen Laser Particle Counter 28.3L/Min Flow Y09-310NW

Product Details:
Place of Origin: JIANGSU
Brand Name: SUJING
Model Number: Y09-310NW
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Carton
Delivery Time: 5 work days
Payment Terms: T/T
Supply Ability: 500unit/per month
Detailed Product Description
Size Channels: 0.3, 0.5, 1, 3, 5, 10 μm Flow Rate: 28.3L/min (Imported Pump)
Operating Time: More Than 5.5 Hours Weight: 3.5kg
Class: ISO14644-1:2015 Maximum Rated Particle Concentration: 35000 Particles/L
High Light:

7inch Touch Screen Laser Particle Counter

,

28.3L/min Flow Laser Air Particle Counter

,

80W Laser Particle Counter

Y09-310NW Air Laser Particle Counter For Clean Room



The basic operating principle of the Y09-310NW Particle Counter is a laser scattering pulse signal of an aerosol particle output from an optical sensor which is processed and counted based on digital signal processing. The setting of measurement parameters, results display, and data storage are all controlled and realized by an internal microprocessor (MCU).



The specification of portable particle counter



Outside Dim 245*268*160 (mm3); (Wide*Deep*High)
Display 7 inch touch screen
Weight 3.5Kg
Max. Consumption 80W
Power Source DC16.8V built-in Lithium Battery; AC 220V ± 10%
Size Channels 0.3, 0.5, 1, 3, 5, 10 μm
Calculation 95% UCL calculation, can display and print particle concentration (particles / cubic meter, particles /cubic feet)
Flow Rate 28.3L/min (Imported Pump)
Sample Time 6s---999999s (Selectable)
Cycles 0-99
Hold Time 0-9999s
Delay Time 5-999s
Zero Court <=10min
Location 1-99
Alarm ISO Class
Printer Built-in Thermal Printer
Data Storage 20000Samples /300 Samples of UCL (With PC Software)
Light Source Laser Diode (30,000 hours Mean Time Between Failures)
Counting efficiency 50% @ 0.3μm and 100% for particles >0.45μm (ISO21501)
Maximum Rated Particle Concentration 35000 particles/L
Operating Time More than 5.5 hours
Environmental Temperature Temperature :10 -35; Humidity:20%-75%RH; Atmosphere Pressure:86Kpa-106Kpa



7inch Touch Screen Laser Particle Counter 28.3L/Min Flow Y09-310NW 0



Features of air particle counter

1. Sample volume 28.3 LPM (1.0CFM).
2. Simultaneously display of up to six particle sizes

3. 20000-record data storage memory

4. Meet the requirements of ISO14644-1:2015

​5. Built-in Thermal Printer

6. Low power display
