DC16.8V SUS316L Laser Sensor Air Particle Counter 100LPM

Certification
China Suzhou Sujing Automation Equipment corporation limited certification
China Suzhou Sujing Automation Equipment corporation limited certification
I'm Online Chat Now

DC16.8V SUS316L Laser Sensor Air Particle Counter 100LPM

DC16.8V SUS316L Laser Sensor Air Particle Counter 100LPM
DC16.8V SUS316L Laser Sensor Air Particle Counter 100LPM DC16.8V SUS316L Laser Sensor Air Particle Counter 100LPM DC16.8V SUS316L Laser Sensor Air Particle Counter 100LPM DC16.8V SUS316L Laser Sensor Air Particle Counter 100LPM

Large Image :  DC16.8V SUS316L Laser Sensor Air Particle Counter 100LPM

Product Details:
Place of Origin: China
Brand Name: Sujing
Model Number: Y09-5100
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Carton
Delivery Time: 5 work days
Payment Terms: T/T
Supply Ability: 800/per month
Detailed Product Description
Name: Particle Counter Flow Rate: 100LPM
Warranty Time: 1 Year Weight: 8.4kg
Operating Time: More Than 5.5 Hours Maximum Rated Particle Concentration: 35000 Particles/L
High Light:

100LPM Laser Sensor Air Particle Counter

,

DC16.8V Air Particle Counter

,

SUS316L Cleanroom Air Particle Counter

Flow Rate 100LPM Laser Sensor Air Particle Counter



The basic principle of laser particle counter is the detection of optical sensor. After scattering by particles, the laser is received by photosensitive element and generates pulse signal. The pulse signal is output and amplified, and then digital signal processing is carried out. By comparing with standard particle signal, the comparison result is expressed with different parameters.



Specification of particle counter

Model

Y09-5100

DC16.8V SUS316L Laser Sensor Air Particle Counter 100LPM 0

Y09-550

DC16.8V SUS316L Laser Sensor Air Particle Counter 100LPM 1

Y09-350DC16.8V SUS316L Laser Sensor Air Particle Counter 100LPM 2
Outside Dim 268×295×192(mm3)
Display 7inch Color Screen
Weight 8.4kg
Max.Consumption 80W
Power Source DC16.8V
Size Channels 0.5, 1, 3, 5, 10, 25μm 0.3,0.5,1,3,5,10μm
Flow Rate 100L/min 50L/min
Sample Time 6~999999s(Selectable)
Zero Count ≤10min
Hold Time 0-9999s
Delay Time 5-999s
Printer Built-in Thermal Printer
Data Storage 20000 Samples/300Samples of UCL(With PC Software)
Maximum Rated Particle Concentration 35000 particles/L
Operating Time 3 hours 5 hours
Environmental Temperature:10~35; Humidity:20%~75%RH; Atmosphere Pressure:86~106Kpa
Material SUS316L Stainless Steel
Class ISO14644-1:2015/GMP:2015









DC16.8V SUS316L Laser Sensor Air Particle Counter 100LPM 3

Related products

Model

Y09-110

Y09-310NW

Y09-3016HW






DC16.8V SUS316L Laser Sensor Air Particle Counter 100LPM 4





DC16.8V SUS316L Laser Sensor Air Particle Counter 100LPM 5



DC16.8V SUS316L Laser Sensor Air Particle Counter 100LPM 6



Size Channels 0.1,0.2,0.3,0.5,0.7,1.0μm 0.3,0.5,1,3,5,10μm
Flow Rate 28.3L/min 2.83L/min
Display 7inch Color Screen 4.3inch Color Screen





DC16.8V SUS316L Laser Sensor Air Particle Counter 100LPM 7

Suzhou Sujing Automation Instrument Equipment Co., Ltd. (herein after referred to as Sujing Instrument) is boasting the largest market share in the particle measurement field in China, with complete integration of scientific research, development and production.

Sujing Instrument is one subsidiary company of Sujing Group.(Sujing Group has 11 subsidiary companies)

Sujing brand has been granted the honor of "China Famous Brand" since 1983. Sujing Group has been keeping the first place among competitors in the same industry for 35 years in a row.
The mission of Sujing Instrument is to provide products and services accociated with particle measurement and monitoring, which are application driven.





Sujing instrument is an ISO 9001:2015 Registered Company
