Name: | Six Size Channels Condensation Portable Air Particle CounterCondensation Particle Counter For Multi-Point Facility Monitoring | Outside Dim: | 300*360*126mm3 (width*length*high) |
---|---|---|---|
Size Channels: | 0.1, 0.2, 0.3, 0.5, 1.0 μm | Weight: | 6kg |
Zero Time: | <=10min | Environmental Temperature: | Temperature :10 -35℃; Humidity:20%-75%RH; Atmosphere Pressure:86Kpa-106Kpa |
Highlight: | Y09-101 Condensation Particle Counter,80W Condensation Particle Counter,28.3L/min Condensation Particle Counter |
Condensation Particle Counter For Multi-Point Facility Monitoring
The condensation particle counter leads the industry as the first of its kind portable particle counter with 0.1 micron sensitivity and 1.0 CFM (28.3 LPM) flow rate using laser diode technology. Conventional HeNe (Helium Neon) particle counters require frequent cleaning, periodic Laser tube replacement and suffer low concentration limits.
The specification of Condensation Particle Counter
Specification | Y09-101 particle counter | Y09-110 particle counter |
Outside Dim | 300*360*126mm3 (width*length*high) | |
Display | 7 inch color screen | |
Weight | 6kg | 7Kg |
Max. Consumption | 48W | 80W |
Power Source | AC 220V ± 10% | |
Size Channels | 0.1, 0.2, 0.3, 0.5, 1.0 μm | |
Flow Rate | 2.83L/min | 28.3L/min |
Zero Time | <=10min | |
Maximum Rated Particle Concentration | 35000 particles/L | |
Environmental Temperature | Temperature :10 -35℃; Humidity:20%-75%RH; Atmosphere Pressure:86Kpa-106Kpa |
Features of Condensation Particle Counter
Application of Condensation Particle Counter
• Cleanroom Monitoring
• Facility Certification Testing
• Trend Analysis
• Tool and Equipment Testing
• Multi-Point Facility Monitoring
• Compressed Gas Monitoring
(with High Pressure Controller)
